20-0545 2009-2015 Corvette ZR1 / Camaro ZL1 Radium Plumbing Kit

The Radium Plumbing Kit fits 2009-2015 Corvette ZR1/Camaro ZL1/Cadillac CTS-V. Part number 20-0545.

Features

• Complete plug and play plumbing hardware for the Radium 20-0362 LS9/LSA fuel rails (sold separately)
• SAE quick connect adapting the OEM feed line into two 6AN PushLok fuel lines
• 8AN ORB plugs included for all unused rail ports
• All fuel types including E85

Kit Includes

• 1x SAE quick connect OEM feed line adapter
• 2x 6AN PushLok fuel lines (one per rail)
• 8AN ORB plugs for all unused ports
• Fuel rails (20-0362) NOT included

Applications

• 2009-2013 Chevrolet Corvette ZR1 (LS9)
• 2012-2015 Chevrolet Camaro ZL1 and 2009-2015 Cadillac CTS-V (LSA)
• 2013-2017 HSV GTS, Clubsport R8, Maloo R8, Senator Signature, GTSR/GTSR W1; 2014+ Equus Bass 770
• For the Radium 20-0362 fuel rails

Complete the System

This kit handles the rails. If the build is going return-style from the tank forward, the hanger plumbing kits require both this kit and the 20-0362 rails:

• Fuel rails (20-0362): the twin twelve-port LS9/LSA rails this kit is built around
• Fuel hanger plumbing kit, CTS-V (20-1325-03 / 20-1325-05): full return conversion for 2008-2015 CTS-V, feeding the RH rail and regulating at the LH rail
• Fuel hanger plumbing kit, Camaro (20-1326-03 / 20-1326-05): the 2010-2015 Camaro version, with the feed and FPR rails reversed relative to the CTS-V
• Fuel pump hanger, 08-17 GM cars (20-1320 / 20-1322): the in-tank hanger supporting one to three aftermarket pumps
