20-1113 Mazda 13B-RE/REW Radium Top Feed Primary Fuel Rail Conversion Kit

The Radium Top Feed Primary Fuel Rail Conversion Kit fits Mazda 13B-RE/REW. Part number 20-1113.

Features

• High flow primary rail for the 13B-RE and 13B-REW rotary engines; converts to top feed injection
• Anodized black aluminum, large internal bore, all fuels including E85
• 3x 8AN ORB ports; center port for OEM fuel temp sensor (14-0421), pressure transducer, or pulse damper
• 14mm lower injector seats included, Viton O-ring sealed, compatible with or without OEM diffusers
• Insulating phenolic spacers, washers, and stainless steel hardware included
• Verified injectors: Injector Dynamics ID1050/ID1300/ID1700/ID2600-XDS-34-14-14 (NOT included)

Kit Includes

• 1x Black anodized high flow primary fuel rail (20-1113)
• 14mm lower injector seats with Viton O-rings
• Insulating phenolic spacers and washers, stainless steel hardware
• Fuel injectors and port fittings NOT included

Applications

• 1992-2002 Mazda RX-7 FD3S (13B-REW)
• 1990-1995 Mazda/Eunos Cosmo (13B-RE)
• Verified: ID1050/1300/1700/2600-XDS-34-14-14 injectors
